G.M. International D1064S Strain Gauge Bridge Isolating Converter
G.M. International D1064S (Part No. D1064S) is a strain gauge bridge isolating converter designed to interface strain gauge sensors and load cells with control and monitoring systems. It provides signal isolation, conversion, and conditioning, ensuring accurate and reliable measurement in industrial weighing, force measurement, and process control applications
BRAND
G.M. International
TYPE
Strain Gauge Bridge Isolating Converter
PART NO.
Converter D1064S
MODEL
D1064S
Full Technical Specifications ▶
| Parameter | Value / Description |
|---|---|
| BRAND | G.M. International |
| TYPE | Strain Gauge Bridge Isolating Converter |
| PART NO. | Converter D1064S |
| MODEL | D1064S |
| Voltage Rating | 24 V DC Nominal (Operating range: 20 to 30 V DC) | \(U_m = 250\text{ Vrms}\) maximum safety voltage allowed |
| Application | Galvanically isolated interface between a Safe Area PLC/DCS and Hazardous Area load cells/strain gauges |
| IEC Standards | IECEx Certified (BVS 07.0027X); SIL 2 compliant according to IEC 61508:2010 |
| Intrinsically Safe Parameters | Labeled with output parameters \(U_o = 5.9\text{ V}\), \(I_o = 196\text{ mA}\), \(P_o = 576\text{ mW}\), \(C_o = 39\ \mu\text{F}\), and \(L_o = 0.93\text{ mH}\) at safety terminals 9–10–11–12–13–14 |
| Load Cell Compatibility | Capable of powering up to four \(350\ \Omega\) load cells, five \(450\ \Omega\) load cells, or ten \(1000\ \Omega\) load cells in parallel |
| Output Flexibility | Converts millivolt (\(1\text{ to }4\text{ mV/V}\)) strain gauge input signals into user-programmable analog options like 0/4–20 mA, 0/1–5 V, or 0/2–10 V signals |
| Ambient Temperature Range | Designed for extreme industrial environments spanning from \(-20^{\circ}\text{C}\text{ to }+60^{\circ}\text{C}\) |
| Production Timing | Labeled code shows a production date of 06-15 (June 2015) |
| Serial Number | 151730088 |
| Made In | Italy (Villasanta, MI) |
| REF NO | 519 |
