Danfoss Pressure Transmitter / Industrial Pressure Sensor MBS 33M
The Danfoss MBS 33M (060G3127) is a robust industrial pressure transmitter designed for accurate and reliable pressure measurement in demanding marine and industrial applications. It features a 0–16 bar pressure range, 4–20 mA output, and 10–30 VDC supply, delivering stable performance with excellent vibration resistance and a durable stainless-steel construction for long-term operation in harsh environments.
BRAND
Danfoss
TYPE
Pressure Transmitter / Industrial Pressure Sensor
PART NO.
060G3127
MODEL
MBS 33M
Full Technical Specifications ▶
| Parameter | Value / Description |
|---|---|
| BRAND | Danfoss |
| TYPE | Pressure Transmitter / Industrial Pressure Sensor |
| PART NO. | 060G3127 |
| MODEL | MBS 33M |
| MANUFACTURER | Danfoss A/S |
| Pressure Range | 0 to 16 bar (0 to 1.6 MPa) |
| Maximum Working / Burst Pressure (PB/MWP) | 50 bar (5 MPa) |
| Output Signal | 4–20 mA (2-wire current loop) |
| Supply Voltage | 10–30 V DC |
| Electrical Connection | Pin Terminal Connection |
| Pin Configuration | +Supply: Pin 1, –Common: Pin 2 |
| Pressure Reference | Gauge Pressure |
| Application | Industrial process control, marine automation systems, hydraulic & pneumatic systems, compressors, pumps, engine monitoring, OEM machinery, pressure monitoring and control |
| Housing Material | Stainless Steel |
| Made In | China |
| REF NO. | 1385 |
