ABB CT-ERS.21S On-delay Time Relay 1SVR730100R0300
ABB CT-ERS.21S on-delay time relay with Part No. 1SVR730100R0300 and wide input supply range A1-A2: 24–240V AC/DC, 50/60Hz. Time range adjustable from 0.05 seconds to 300 hours for industrial timing applications. Features 2 changeover (2 C/O) output contacts with rated operational data including AC15 230V 3A and DC13 24V 2A. UL listed industrial control equipment compliant with IEC/EN 61812-1 and IEC/EN 60947-5-1 standards.
BRAND
ABB
TYPE
CT-ERS.21S
PART NUMBER
ABB CT-ERS.21S On-delay Time Relay 1SVR730100R0300
MODEL
1SVR730100R0300
Full Technical Specifications ▶
| Parameter | Value / Description |
|---|---|
| MANUFACTURER | ABB |
| TYPE | CT-ERS.21S |
| PART NUMBER | ABB CT-ERS.21S On-delay Time Relay 1SVR730100R0300 |
| MODEL | 1SVR730100R0300 |
| Us: | 1svr730100r0300 |
| A1-a2 | ~ 24-240v 50/60hz |
| Ithe: | 4a |
| U Imp | 4kv |
| Fuse | 10a Fast |
| Ac15 | 230v Ma Dc13: 24v 2a |
| Iec/en | 61812-1 |
| Iec/en | 60947-5-1 |
| Gb | 14048.5 |
| Made In | Germany |
| Ref.No. | 510 |
